Product overview
The circuit breaker is an outdoor small porcelain column structure, equipped with a CT14 spring operating mechanism; the mechanism is integrated with the body, simple to install, easy to debug, reliable in action, and suitable for frequent operating locations; the mechanism has a service life of more than 3,000 times; the sealing performance is reliable , using imported sealing gasket, the dynamic seal adopts "V" type sealing ring with elastic arrow pressure compensation structure, the transformer secondary wiring board is matched by the cooperative enterprise, ensuring that the annual air leakage rate is <1%; the included current transformer adopts micro Crystal alloy material with high magnetic permeability, the accuracy can reach 0.2 level or 0.2s level. According to user needs, 12 transformers can be included.
Use environmental conditions
1. Altitude: no more than 2,500 meters; plateau type 4,000 meters;
2. Ambient temperature: -30°C-+40°C (special requirements -40C-+40C);
3. Relative humidity: daily average not greater than 95%, monthly average not greater than 90% (25C)
4. Wind speed: no more than 35m/s; pollution level is level 1; the creepage distance of the porcelain sleeve is 1050mm (1320mm) (the nominal creepage distance is not less than 25mm/kV);
5. Sunshine: 0.1w/cm?;
6. Ice coating: 10mm (MAX);
7. Earthquake conditions: vertical acceleration 0.3g; horizontal acceleration 0.15g (max) in places without flammable substances, explosion hazards, chemical corrosion and severe vibrations
